Product Details:
|
| Name: | Automatic Corrugated Cardboard Box Making Stitching Machine | Place Of Origin: | Hebei, China |
|---|---|---|---|
| Stapling Speed: | 250nalis/min | Certification: | CE ISO9001 |
| Function: | Stitching Carton Box | Weight: | 4500kg |
| After Warranty Service: | Video Technical Support, Online Support, Spare Parts, Field | Stitching Distance: | 30-120mm |
| Key Selling Points: | Energy Saving | Keyword: | Stitching Machine |
| High Light: | 3 layers carton box stitching machine,corrugated cardboard carton box stitching machine,3 layers corrugated box stitching machine |
||
Automatic Corrugated Cardboard Box Making Stitching Machine
Made by careful designing the DZX series stapling machine absorbs the advantages of the same kinds of products at home and abroad.
It has the advantages such as novel appearance,high-speed,steady revolving,solid stapling,adopting base mold hard alloy,long using life an so on
Technological Parameter
| Model | Stapling speed | Thickness of stapling | Length of the stretched arm |
Shape size (mm) |
weight(kg) |
Power required (kw) |
Flat wire specifications |
| DZX-600 | 120 staples/min | 3,5 layers | 600 | 1100×600×1760 | 300 | 0.25kw | 18#,20# |
| DZX-900 | 250 staples/min | 3,5,7 layers | 900 | 1400×600×1760 | 400 | 0.37 | 16# 17# 18# |
| DZX-1200 | 250 staples/min | 3,5,7 layers | 1200 | 1700×700×1820 | 600 | 0.37 | 16# 17# 18# |
| DZX-1400 | 250 staples/min | 3,5,7 layers | 1400 | 1900×700×1820 | 800 | 0.75 | 16# |
| DZX-1600 | 250 staples/min | 3,5,7 layers | 1600 | 2100×700×1820 | 900 | 0.75 | 16# |
| DZX-1800 | 250 staples/min | 3,5,7 layers | 1800 | 2300×700×1820 | 1000 | 1.1 | 16# |
