Product Details:
|
| Function: | High Speed Corrugated Flute Laminating And Paper Flute Laminating Machine | Automatic Grade: | Automatic |
|---|---|---|---|
| Warranty: | One Year | Driven Type:: | Electric |
| Voltage: | 380v/50hz 220v/60hz | Core Components: | PLC, Bearing, Gearbox, Motor |
| Base Material: | Cast Iron | Feeding Way: | Automatic Feeding |
| After Warranty Service: | Video Technical Support | ||
| High Light: | 1100mm flute laminator machine,electric driven flute laminator machine,1100mm automatic flute laminator machine |
||
Main features:
1. Automatic feeding for top sheet and bottom sheet.
2. Integrated control with PLC can provide easy operation & trouble shot during production. Safety for user is considered and widely used in the machine design.
3. Famous international brand of components like bearing, electrical parts are used in the critical functioning part of the machine.
4. Elastic front register positioning, the bottom sheet does not exceed the top one, the front-and-back distance between the top sheet and the bottom sheet can be adjusted.
5. suitable for laminating bottom cardboard more than 450g/m2 with top paperboard, laminating paperboard with A/B/C/D/E flute corrugated cardboard, and laminating corrugated board.
6. Standard top the paper correction system, to inprove the accuracy of the laminating.
Technical parameter:
|
Model
|
1300
|
1450
|
1600
|
|
Max size
|
1300 x 1100mm
|
1450 x 1100mm
|
1600 x 1400mm
|
|
Min size
|
350 x 350 mm
|
350 x350mm
|
450 x 450 mm
|
|
Laminate precision
|
≤±1.5mm
|
≤±1.5mm
|
≤±1.5mm
|
|
Max speed
|
6000 Sheets/h
|
6000 Sheets/h
|
6000 Sheets/h
|
|
Total Power
|
12 kw
|
12 kw
|
13 kw
|
|
Machine length
|
12.5 M
|
12.5 M
|
15 M
|
|
Weight
|
6.8 T
|
7.2 T
|
8.0 T
|
