Paper Feeding Parts:
1. The leading edge of the paper feed can be moved left and right, which improves the coordination performance of the positive mark and the side mark of the cardboard. 2. Adopt the belt leading edge suction paper feeding method, accurate and reliable. 3 The use of high-grade electromagnetic clutch and electromagnetic brake system, so that the paper supply part can be controlled separately, simple and reliable operation. 4. The height of the paper press wheel is adjustable, suitable for cardboard thickness of 2-8mm. 5. Linkage with the folding part, frequency conversion speed regulation, design speed 0-150m/min, paper supply speed 0-140m/min. 6. The front and side baffles of the paper supply department can be electrically adjusted left and right, and the paper holder can be electrically adjusted front and back.
Gluing And Folding Parts:
1. The main motor adopts frequency conversion speed regulation, the system has no noise, flexible speed regulation and stability. 2. Imported high friction belt conveyor cardboard, automatic stacking. 3. The automatic glue stick adopts stainless steel wheel glue, which can adjust the amount of glue, the amount of glue is uniform, the left and right electric adjustment, no fault, and the glue is saved. 4. The folding part is equipped with cardboard correction device and indentation correction device. 5. The folding part has two rows of adjustable inner positioning guide wheel system, and the molding accuracy is higher. 6. Folding speed 0-140m/min. 7. Electric adjustment of left and right guide folding device, reducer equipped with program encoder, to achieve memory function, can intelligently store multiple orders, so that the equipment to work more intelligent, more convenient, more faster.
1. The head of the stitching box department adopts the lifting function, which improves the speed of changing the order of the nail box mode conversion sticky box mode. 2. Japan Mitsubishi original imported double servo drive, accurate precision, mechanical transmission part is reduced, can effectively reduce the failure rate of machinery. 3. Touch screen operation, parameter (stitching pitch,stitching number, stitching type, tailgate) transformation is convenient and fast. 4. The entire control system adopts PLC control system. 5. Rear electric bezel, using stepper motor drive, the size is accurate, and the size change is more convenient and fast. 6. Bottom mold, blade made of Japanese tungsten steel (wear-resistant). 7. The whole group of nail heads are all made of special steel, and the computer gong is precision processed. 8. Single stitchers, double stitchers (manual adjustment), one-time completion, can be adapted to different customers for different requirements of stitching types. 9. Changing the carton size and adjusting the carton nail spacing can be completed in only one minute, which greatly saves time and is convenient to operate. 10. Mechanical speed: 800 stitchers/min. 11. Stitching pitch: 20-120mm any adjustable. 12. Electric adjustment of the gap between the press rollers. 13. The whole machine electrical isolation transformer protection function; 14. Automatic wire feeding system, 20KG flat wire, save time.
Counting Accumulation Output Part
1. Using PLC programming controller and touch screen digital control, simple operation, reliable action without stopping input data, automatic counting, automatic stacking, neat output. 2. The main motor of the counting department is frequency conversion speed regulation, the speed is adjustable, and the boot is stable and reliable. 3. Use the belt to convey the carton, stack neatly, the speed is 0-140m/min. 4. The use of the slapping board to hit the carton, with the function of guiding deviation, the deviation is very small. 5. Counting and rolling out using pneumatic mode, PLC point control, reliable action, accurate and fast. 6. The output part adopts the synchronous pressing mode of the bottom conveyor belt and the upper compression belt, so that the finished carton is firmly adhered to and neatly output without misalignment. Stack height 5-20 sheets. 7. The upper part of the counting stack is pressed tightly with the belt device that can be electrically adjusted up and down.
