Board Sheet Cutter Corrugated Cardboard Machine Single Facer

Board Sheet Cutter Corrugated Cardboard Machine Single Facer
Board Sheet Cutter Corrugated Cardboard Machine Single Facer
Board Sheet Cutter Corrugated Cardboard Machine Single Facer Board Sheet Cutter Corrugated Cardboard Machine Single Facer Board Sheet Cutter Corrugated Cardboard Machine Single Facer Board Sheet Cutter Corrugated Cardboard Machine Single Facer Board Sheet Cutter Corrugated Cardboard Machine Single Facer Board Sheet Cutter Corrugated Cardboard Machine Single Facer Board Sheet Cutter Corrugated Cardboard Machine Single Facer

Large Image :  Board Sheet Cutter Corrugated Cardboard Machine Single Facer

Product Details:
Place of Origin: CHINA
Brand Name: Hh
Certification: CE EAC
Model Number: 1600mm
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiated
Packaging Details: plastic
Delivery Time: 5-8 days
Payment Terms: T/T
Supply Ability: 30 sets every month
Contact Now

Board Sheet Cutter Corrugated Cardboard Machine Single Facer

Description
Condition: New Warranty: One Year
Application: Corrugated Carton Box Driven Type: Electric , Pneumatic
Automatic Grade: Full Atuomatic, Computerized Dimension(l*w*h): 3500*2000*2200mm
Packaging Material: Plasstic, Metal, Wood Name: Corrugated Carton Box Machine
Highlight:

Board Sheet Cutter Corrugated Cardboard Machine

,

Corrugated Cardboard Machine Single Facer

,

Single Facer Corrugated Box Making Machine

Corrugated Carton Box Machine



Use and Characteristics:
1. Design speed: 100m/min.
2. Effective width: 1400mm- 1800mm.
3. Corrugated roller: φ 280mm.
4. The driving reducer adopts oil penetration lubrication, reducing noise, universal joint drive and isolating power source.
5. Upper roller, pressure roller and rubber roller lift, all with pneumatic control.
6. The guide paper adopts vacuum adsorption, with air volume adjustment device, to maintain the stability of corrugated type in
high speed.
7. The roller and pressure roller bearings are lubricated with high temperature resistance grease.
8. The gelatinize part adopts automatic circulation for glue.
9. The upper and lower corrugated roller adopts 48CrMo high quality chromium aluminum alloy steel, after heat treatment, the
hardness is grinding on the surface of hrc58o-60o.
10. The surface of the rubber roller has been treated with the mesh cut and chrome plating.
11. Manual or electric separation device.
12. The machine can operate independently or without independent operation, and the main power converter control (optional).
FAQ
1.Q:Are you a manufacturer?
A: Yes ,we make all the machines related to corrugated cardboard and carton box.

2. Q:Do you have export licence ?
A: Yes ,we have export licence and we can export by ourselves .

3. Q:Where are you located ?
A: We are located in dongguang city ,cangzhou city ,hebei pronvice , China ,

4. Q:How to travel to your city ?
A: Our nearest airport are beijing international airport , and jinan airport , our nearest high speed train station is cangzhou
west station.It only takes two and a half hours to my city by car ,and only 1 hour from beijing south station to cangzhou west
station by high speed train .

5. Q:About quality control and delivery?
A: Inhouse inspection and third party inspection. Our delivery time is on time.

6. Q:The process of buying machines from our company ?
A: Describe your requirements --- quote the price - accpet the price - make the contract -- prepare the machine - check the
machine-ship the machine

7. Q: Do you have any working machine for us to visit?
A: Yes,We have running machine near our factory also in our city, so we can arrange the visiting.

8. Q: What is the warranty time of the machine?
A: Our machines have One YEAR WARRANTY. Engineers are available for oversea service.

9. Q:Is it safe on the payment for me as we are the first cooperation?
A: We can do the trade assurance on Alibaba, which will guarantee your products receiving. We also accept other safe payment ways
you want.
