Product Details:
Place of Origin: CHINA
Brand Name: HH
Certification: CE ISO
Model Number: 2000mm
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiated
Packaging Details: plastic
Delivery Time: 5-8 DAYS
Payment Terms: T/T
Supply Ability: 60 sets every month

Semi Pasting Carton Folder Gluer Machine Semi Automatic

Description
Highlight:

Semi Pasting Carton Folder Gluer

,

Semi Automatic Carton Folder Gluer

Function :

Corrugated Carton Box Machine is used for the small and middle carton factory . it us used for the final process working produce . simple operation . solid binging , little noise . the machine speed 5-10 times as fast as the stapler machine .



  1. worktable

the worktable can go up and down by photoelectric control , increase the work efficiency .

  1. press and revise
    1. the carton is agglutinate by second press after the carton is gelatinized
    2. the machine can auto revise , the carton size is exact . shun the carton glue unit have the superposition .
    3. the fan have the air-dry function .
    4. the machine can auto counter , the machine have the rlatn photoelectric , the carton can auto export when the carton arrive to the set number .
  2. export width

the carton can auto export when the carton arrive to the set number .



Main Technical parameter

Max size carton length 2800mm
Min size carton length 600mm
Max size carton height 2000mm
Min size carton height 250mm
Carton worktable height 900mm
Power 4kw
Speed 40 piece/min
Weight 1500kg
Volume 3800*1800*1700mm
